| Article number: | meha242400996 |
| 01. FRAME | BIG.SEVEN TFS III; MAT aluminium; 27.5 WHS; 135x9 AST; BSA BBR |
| 02. SIZES | XS-S |
| 03. FORK | Suntour XCT30 HLO; Coil; 100 STR; Lockout; 27.5x2.25" max. WHS |
| 04. GEARS | 3x8 |
| 05. CHAINWHEEL | Shimano TY301; 42-34-24 ATC |
| 06. CRANK LENGTH | 170 mm-XS/S, 175 mm-M/L |
| 07. BOTTOM BRACKET | Shimano BB-UN101 73-123 |
| 08. CASSETTE | Sunrace CSM558AU; 11-32 teeth; 8 speed; Nickel |
| 09. CHAIN | KMC Z8.1 |
| 10. DERAILLEUR - FRONT | Shimano FD-TY600 |
| 11. DERAILLEUR - REAR | Shimano RD-M3020-8; SGS |
| 12. SHIFTER - FRONT | Microshift TS39 [or Shimano ST-EF505] |
| 13. SHIFTER - REAR | Microshift TS39 [or Shimano ST-EF505] |
| 14. DROPPER LEVER | - |
| 15. BRAKES | Tektro M275 [or Shimano BR-MT200] |
| 16. ROTOR - FRONT | Shimano RT10; 160 mm |
| 17. ROTOR - REAR | Shimano RT10; 160 mm |
| 18. HANDLEBARS | MERIDA CC; MAT aluminium; 690 WHB; 15 RHB |
| 19. STEM | MERIDA CC; MAT aluminium; 31.8 DSH; 6 ASD |
| 20. STEM LENGTH | 70 mm-XS/S, 80 mm-M, 90 mm-L |
| 21. HEAD SET | MERIDA M2345 |
| 22. SEAT POST | MERIDA CC; MAT aluminium; 30.9 DSP; 15 SSB |
| 23. SADDLE | MERIDA Sport comfort |
| 24. HUB - FRONT | Shimano TX505; 100x9 WHF; 32 SPH; Centerlock |
| 25. HUB - REAR | Shimano TX505; 135x9 WHR; 32 SPH; Centerlock |
| 26. AXLE - REAR | Quick Release |
| 27. SPOKES | Black steel |
| 28. RIMS | MERIDA CC; 17 IWR; MAT aluminium |
| 29. TYRES | MERIDA K1080; 27.5x2.2"; wire |
| 30. PEDALS | VP VPE-891 |
| 31. OTHER | - |
| 32. MAX. RIDER WEIGHT | 135kg |
